Aspect Ratio 16:9
Screen size (inches) 84
Resolution 3840 x 2160
Brightness (cd/m2) 500
Contrast Ratio 1400:1
Response Time (ms) 12
Viewing Angle (°)178 x 178
Colour Depth (Num of Colours) 1.06 Billion
Video
Max Input Resolution 3840 x 2160@30Hz (HDMI, Display Port), 1920 x 1080@60Hz (RGB, DVI-D)
Recommended Resolution 3840 x 2160@30Hz (HDMI, Display Port)
H-Scanning Frequency 30 ~ 83kHz (RGB, HDMI/DVI-D/DP)
V-Scanning Frequency 56Hz ~ 75Hz (RGB), 56Hz~60Hz (HDMI/DVI-D/DP)
Pixel Frequency 300MHz(HDMI, Display Port), 148.5MHz(RGB, DVI-D)
Sync Compatability Separate / Composite / Digital
Video Input RGB, HDMI, DVI-D, Display Port, Composite
Picture Mode Intelligent Sensor/Vivid / Standard / Cinema / Game/ Expert1/Expert2
Colour temperature Warm / Medium / Cool
Connectivity - Input
Digital Main : HDMI(1), DVI-D(1) Option1 (Included) : HDMI(1), Display Port(1) with HDCP for all input
Analog Main : RGB(1) Option1 (Included) : Composite(1)
Audio Main : RGB/DVI-D/AV
External Control Main : RS232C(1), RJ45(1), IR(1)
USB 2
Connectivity - Output
Digital DVI-D(1)
Analog Component(1), Composite(1), RGB(1) (Shared with D-Sub)
Audio External Speaker
External Control RS232C(1), IR(1)
Audio
Audio Power 20W (10W x 2)
Balance Yes
Speaker On/off Yes
Clear Voice II Yes
Sound mode Standard , Music, Cinema , Sports , Game
Special Features
Temperature Sensor Yes
Auto Brightness sensor Yes
Brightness/Contrast/Backlight Yes
Position/Size Yes
Auto Config/Phase Yes
Advanced Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction, Digital Noise Reduction, Gamma, Black Level
Input Label Yes
Auto Power/Source Memory Yes
Key Lock Yes
DPM Select Yes
Power Indicatior On/Off Yes
File Play with USB Yes
Energy Saving Mode Yes (Minimum, Medium, Maxium)
Standard (Certification) & VESA Mounting
UL(cUL) Yes
CB scheme Yes
VESA Mounting 600 x 400
Power
Power Supply 100-240V, 50/60Hz
Power Type Built-in Power
Power Consumption Typ.: 350W, Smart Enegy Saving: 200W, DPM: 1.5W, Power off: 0.5W
